AXISFLYING C204 2004 3-3.5 INCH CINEWHOOP/TOOTHPICK MOTORS – 4S/6S 2650KV/3500KV
R340
The Axisflying C204 is a premium cinematic brushless motor engineered specifically for 3-inch cinewhoops and 3.5-inch cruising setups. Featuring a 2004 stator and Axisflying’s innovative IP53-rated Bearing Shield Technology, it delivers the high torque, incredible smoothness, and precision control required for professional single-take cinematic flights.
- KV Options: Selectable 2650KV (6S) or 3500KV (4S)
- Stator Size: 2004 for optimal torque on 3-inch and 3.5-inch platforms
- Bearing Shield Technology: IP53 dustproof and waterproof bearing protection
- Mounting Pattern: Standard 12x12mm (M2) footprint
- Quantity: Per Motor
Axisflying C204 Cinematic Brushless Motor (2650KV / 3500KV)
The Axisflying C204 motor is purpose-built for cinematic FPV pilots who demand absolute precision and reliability. Designed around a highly efficient 2004 stator (12N14P configuration), it provides the robust low-end torque necessary to push heavy 3-inch cinewhoops out of dives, while remaining highly efficient for smooth cruising on 3.5-inch platforms. This careful balance of power and throttle resolution ensures delicate control for capturing flawless commercial footage.
Durability in challenging environments is guaranteed by Axisflying’s advanced Bearing Shield Technology (BST). This IP53-rated design seals the bearing placement, effectively keeping out dust, dirt, and moisture. By protecting the internal bearings from environmental contamination and absorbing impact forces, the C204 maintains its factory smoothness across countless flights, significantly reducing the high-frequency jello that can ruin HD camera footage.
Key Features
- Cinematic 2004 Stator: Delivers the perfect blend of reactivity and torque, providing enough raw power for heavy 3-inch cinewhoops while maintaining high efficiency for 3.5-inch cruising setups.
- Bearing Shield Technology (BST): Features an IP53 dustproof and waterproof bearing seal that protects against environmental elements and drastically reduces the chance of crushed bearings in a crash.
- Silky Smooth Power: The 12N14P magnetic configuration provides excellent throttle resolution, allowing for the precise micro-adjustments required in high-stakes commercial filming.
- Tailored KV Options: Available in 2650KV for ultra-smooth 6S power systems, or 3500KV for high-performance 4S builds.
- Robust Wiring: Equipped with high-quality 20AWG, 150mm silicone cables to ensure unrestricted current delivery during peak throttle bursts.
Specifications
| Brand | Axisflying |
|---|---|
| Model | C204 Cinematic |
| KV Options | 2650KV / 3500KV (Selectable) |
| Configuration | 12N14P |
| Stator Size | 2004 (20x4mm) |
| Input Voltage | 4S – 6S LiPo (Dependent on KV) |
| Peak Current | 25A |
| Prop Shaft Diameter | 1.5mm |
| Wire Specifications | 20AWG, 150mm Length |
| Mounting Pattern | 12x12mm (M2) |
| Weight | 15g (Including Cable) |
Recommended Setup
- Motors: Axisflying C204 (Choose KV based on battery voltage)
- Propellers: Gemfan D76-5 (3-Inch) or Gemfan D90-3 (3.5-Inch)
- Electronics: 25A to 35A AIO or 20x20mm ESC Stack
- Battery (4S / 3500KV): 4S 850mAh – 1100mAh LiPo
- Battery (6S / 2650KV): 6S 650mAh – 1050mAh LiPo
What’s in the Box
- 1x Axisflying C204 Brushless Motor
- 4x M2x5mm Motor Mounting Screws
- 2x M2x7mm Prop Lock Screws
- 1x M2x4mm Shaft Lock Screw
- 1x Shaft O-Ring
- 1x Washer
| MOTOR KV | 2650KV (6S), 3500KV (4S) |
|---|
